The DONGCHENG HD074910 Hydraulic Bottle Jack lifts up to 10 tons. It has a minimum height of 230 mm, a lift height of 150 mm, and an adjustable screw of 80 mm. The safety valve protects the jack from overloading. It weighs 5.76 kg net. It is made for mechanics, fleet workshops, and industrial teams.

Key Features

10 ton capacity
Safety valve: helps protect against overload
230 mm minimum height
150 mm lift height, plus 80 mm adjustable screw
5.76 kg net weight
Packed by colour box

Application

Lifting trucks, buses, and heavy vehicles
Fleet and garage maintenance
Workshop and industrial lifting
Machinery and equipment positioning
Construction and agricultural equipment servicing

Technical Specification

Specification	Detail
Brand	DONGCHENG
Model	HD074910
Product Type	Hydraulic Bottle Jack
Capacity	10 ton
Min. Height	230 mm
Lift Height	150 mm
Adjust Height	80 mm
Net Weight	5.76 kg
Safety Valve	Yes
Packaging	Colour box

Safety Note: A jack is for lifting only. Never work under a load supported only by a jack, and use jack stands. Use on firm, level ground, never exceed the rated capacity, and keep the jack upright.

DONGCHENG 10 Ton Hydraulic Bottle Jack with Safety Valve, 230 mm Min. Height (HD074910)-A 10 ton hydraulic bottle jack with a safety valve for trucks and heavy equipment.
