INSIZE 4836-1 Fillet Welding Gage – Accurate Weld Size Measurement Tool

The INSIZE 4836-1 Fillet Welding Gage is a precision measuring tool designed for inspecting and measuring concave and convex fillet weld sizes. Manufactured from high-quality stainless steel, this gauge provides durability, corrosion resistance, and reliable performance in fabrication shops, welding workshops, quality control departments, and industrial inspection applications.

The gauge includes 7 precision blades, with each blade measuring multiple weld sizes, allowing quick verification of weld dimensions. It is ideal for welders, welding inspectors, fabrication engineers, and quality assurance professionals who require accurate weld measurements and compliance with welding specifications.

Features:

Brand: INSIZE
Model: 4836-1
Product Type: Fillet Welding Gage
Measurement Type: Concave & Convex Weld Measurement
Size Range: 3, 4, 5, 6, 8, 9, 10, 11, 12, 14, 16, 19, 22, 25mm
Accuracy: ±0.5mm
Number of Blades: 7
Material: Stainless Steel
Measures both concave and convex weld sizes
Compact and portable design
Easy-to-read measurement markings
Durable stainless steel construction
Suitable for workshop and field inspections
Reliable quality control measuring tool

Specifications:

Measurement Sizes (mm): 3, 4, 5, 6, 8, 9, 10, 11, 12, 14, 16, 19, 22, 25
Accuracy: ±0.5mm
Blades Included: 7
Construction: Stainless Steel

Applications:

Fillet weld inspection
Welding quality control
Fabrication workshops
Structural steel fabrication
Industrial maintenance inspections
Welding certification and testing
Manufacturing quality assurance
Engineering inspection work

INSIZE Fillet Welding Gauge 4836-1 | 3-25mm Stainless Steel Weld Inspection Gauge with 7 Blades
