SURIE 4 BELT POLISHING MACHINE

Mini Polisher is the only machine available in the world which is specially designed to grind, polish, maintain etc. marble, mosaic, stone and slate treads, platforms, landings etc. Its 1 hp heavy-duty motor meets the most demanding requirements of any of the above operations.

Your machine is powered by a 1 hp, mono-phase motor, 220 V, 1440 rpm. Three mini v-belts drive the spindle which is mounted in heavy-duty taper roller bearings to ensure smooth running and long life. The spindle is coupled to the abrasive plate by means of a rubber coupling. The rear wheel assembly is connected to the frame of the machine over a raise-lower device. This enables the operator to balance the machine exactly. You may take your hands off a running machine and it will not wander away but stay where it is. This feature coupled with the front handle control gives excellent control over the operation being performed. The machine has adequate self-weight for all grinding, polishing and buffing applications. The operator need not apply any pressure manually. A spring stand is provided to allow easy and convenient change of abrasives and polishing plates. The electrical cable can be conveniently wrapped onto the cable holder. Central water feeding through the shaft brings the water required for grinding exactly to the right place. The water guard prevents splashing of the entire polishing area.

Your machine is provide with one abrasive plate capable of holding three Butterfly (Munich) / three Casani / three Triangle abrasives. The abrasive plates are easily interchangeable. One spare plain plate may be kept for any eventuality.

Your machine attains its steadiest performance when the wheel side of the machine frame is kept about 25 to 35 mm lower than the handle side. Generally, if the machine pulls to the left you are advised to lower the rear of the machine frame. In case the machine pulls backward you are advised to raise the rear of the machine frame.

Technical Details:

Motor: 1 hp
Weight: 50 kg
Working Dia: 200 mm
Spindle speed: 400 rpm
Dimensions: 580 X 200 X 580 mm
Mini Polisher for treads,platforms & small areas
