Toshon Tig 300 3 Phase MOSFET Inverter Welding Machine
Toshon Tig 300 3 Phase MOSFET Inverter Welding Machine
The Toshon TIG 300 3-Phase MOSFET is a high-performance industrial welding solution designed for precision TIG (Tungsten Inert Gas) and MMA (Stick) welding. Built with advanced MOSFET inverter technology and a durable "three-ply" board structure, it delivers a stable DC output and high efficiency for continuous professional use in fabrication, shipbuilding, and industrial maintenance.
FEATURES:
TECHNICAL DETAILS:
Input Voltage (V) |
AC415V±15% |
Frequency (HZ) |
50/60 |
Rated Input Current (A) MMA/TIG |
18.4/12.7 |
No-load Voltage (V) |
60 |
Output Current Range (A) |
7-300 |
Input Power Capacity (KVA) MMA/TIG |
12/8.4 |
Arc Force (A) |
0-100 |
Duty Cycle (%) |
60 |
No-Load Loss (W) |
60 |
Arc Ignition |
HF |
Efficiency (%) |
85 |
Power Factor |
0.93 |
Insulation Grade |
F |
Housing Protection Grade |
IP21 |
Net Weight (kg) |
19 |
Dimension (inch) |
20*8*15 |
