The Fein ABS 18 Q AS Set 5 Ah is a professional 18V cordless drill driver designed for demanding drilling, screwdriving and tapping applications. It combines a brushless FEIN PowerDrive motor, durable 2-speed all-metal gearbox and the versatile FEIN QuickIN interface, making it suitable for professional work in metal, wood, construction, installation, maintenance and workshops.
The machine delivers a maximum torque of 60Nm for hard applications and 38Nm for soft applications. Its 450–2,000 RPM two-speed range provides flexibility for both controlled high-torque work and faster drilling. With 22 + 1 torque settings, users can accurately adjust the tool according to the fastening application.
The QuickIN system provides excellent versatility by allowing compatible accessories to be changed quickly. The supplied 120Nm QuickIN metal drill chuck features carbide-tipped clamping jaws and high clamping forces, helping provide secure retention of drill bits and accessories.
This 5Ah set includes two GBA 18V 5.0Ah batteries, a GAL 1880 CV AS rapid charger and an L-BOXX 136 tool case, making it a complete solution for mobile professional work. The tool uses the 18V AMPShare battery interface and is compatible with suitable AMPShare and Bosch Professional 18V batteries.
Product Features & Specifications
Brand: Fein
Model:ABS 18 Q AS Set 5 Ah
Part Number:71132462000
Product Number:7 113 24 62 00 0
Product Type:Cordless Drill Driver
Battery Voltage:18V
Battery Capacity:5Ah
Battery Type:Li-ion / ProCORE Li-ion
Battery Interface:18V AMPShare
Motor:Brushless FEIN PowerDrive Motor
Gearbox:2-Speed All-Metal Gearbox
Accessory Interface:FEIN QuickIN
No-Load Speed:450 / 2,000 RPM
Maximum Torque:60Nm Hard / 38Nm Soft
Torque Settings:22 + 1
Drill Chuck:QuickIN Metal Drill Chuck
Chuck Clamping Range:1.5–13mm
Chuck Capacity:120Nm
Maximum Drilling Diameter in Steel:13mm
Maximum Drilling Diameter in Wood:50mm
Maximum Screw Size:8 × 300mm
Tapping Capacity:M10
Impact Function:No – this ABS model is a drill driver and does not have the hammer/impact function found on the ASB series.
Brushless Motor: Provides high efficiency, reduced maintenance and long service life.
FEIN PowerDrive: Designed for efficient power transmission and reliable performance during demanding applications.
All-Metal Gearbox: Provides enhanced durability and reliability for professional workloads.
Mechanical Torque Setting: Allows precise adjustment for different screwdriving requirements.
QuickIN Interface: Enables rapid changes between compatible accessories.
Removable Chuck: Provides greater flexibility when using QuickIN accessories.
Compact Design: Makes the tool easier to handle, particularly in restricted working areas.
Bit Holder: Provides convenient storage for commonly used screwdriver bits.
Belt Holder: Allows convenient carrying during mobile work.
AMPShare Compatibility: Works with compatible 18V AMPShare batteries and chargers.
Bosch Professional Compatibility: Compatible with suitable Bosch Professional 18V batteries.
Electronic Cell Protection: AMPShare battery technology provides protection against overload, overheating and total discharge.
Mobile Working: The cordless design is ideal for professional installation, construction and maintenance work.
Battery & Charging Specifications
Battery Quantity:2
Battery Model:GBA 18V 5.0Ah AS Li-ion
Battery Capacity:5Ah each
Charger:GAL 1880 CV AS Rapid Charger
Battery Platform:18V AMPShare
Compatible Systems:AMPShare and Bosch Professional 18V
The 5Ah battery configuration can provide approximately 1,600 screw connections of 5 × 40mm in timber per battery charge, depending on working conditions.
Key Benefits
18V cordless operation provides excellent mobility without a power cable.
5Ah batteries provide extended runtime for professional applications.
Two 5Ah batteries included allow continuous working by alternating between batteries.
Brushless FEIN PowerDrive motor provides efficient operation and long service life.
60Nm maximum hard torque delivers strong drilling and fastening performance.
