The Fein ASCM 18-4 QM AS 5Ah Set 71161567000 is a professional 18V cordless drill driver designed for demanding drilling, screwdriving, tapping, countersinking and core drilling applications. It features a brushless FEIN PowerDrive motor, a robust 4-speed solid metal gearbox and the versatile QuickIN interface for fast accessory changes.
The drill delivers up to 130Nm maximum torque and provides four no-load speed settings of 430, 850, 2000 and 4000 RPM, allowing users to select the appropriate speed for different materials and applications. The QuickIN solid metal drill chuck has a 1.5–13mm clamping range and carbide-tipped clamping jaws for secure accessory retention.
The ASCM 18-4 QM AS is suitable for drilling in steel and wood, core drilling, hole-saw applications, tapping up to M14, countersinking and screwdriving. The electronic torque shut-off and kickback monitoring provide enhanced control during professional applications.
This 5Ah Set includes 2 × GBA 18V 5.0Ah AS batteries, a GAL 1880 CV AS rapid charger, QuickIN drill chuck, auxiliary handle, belt clip, magnetic bit storage and an L-BOXX 136 tool case.
Product Features & Specifications
Brand: Fein
Product Type:Cordless Drill Driver
Model:ASCM 18-4 QM AS
Part Number:71161567000
Battery Voltage:18V
Battery Capacity:5Ah
Number Of Batteries:2
Battery Interface:18V AMPShare
Battery Type:Li-Ion / ProCORE Li-Ion Compatible
Motor:Brushless FEIN PowerDrive
Gearbox:4-Speed Solid Metal
Accessory Interface:QuickIN
No-Load Speed:430 / 850 / 2000 / 4000 RPM
Maximum Torque:130Nm
Hard Torque:70Nm
Soft Torque:50Nm
Torque Settings:15 + 1
Drill Chuck Capacity:1.5–13mm
Steel Twist Drill Capacity:13mm
Steel Core Drill Capacity:30mm
Steel Hole Saw Capacity:80mm
Wood Drilling Capacity:60mm
Tapping Capacity:M14
Fastening Capacity:10 × 400mm
Weight Without Battery:1.30kg
LED Work Light:Dimmable
Electronic Torque Shut-Off:Yes
Kickback Monitoring:Yes
Electronic Overload Protection:Yes
Tool Case:L-BOXX 136
Key Benefits
130Nm Maximum Torque: Provides powerful performance for demanding drilling, tapping and fastening applications.
18V Brushless Motor: FEIN PowerDrive technology delivers efficient power and supports long service life.
4-Speed Solid Metal Gearbox: Provides four speed levels from 430 to 4000 RPM for optimized working speeds.
QuickIN System: Allows compatible accessories to be changed quickly without additional tools.
QuickIN Metal Chuck: The 1.5–13mm chuck provides strong clamping performance for professional drilling.
M14 Tapping Capability: Suitable for demanding thread-cutting applications.
80mm Hole-Saw Capacity: Supports large-diameter hole-saw applications in steel with suitable carbide hole saws.
60mm Wood Drilling Capacity: Suitable for larger-diameter drilling applications in wood.
15+1 Torque Settings: Allows controlled torque adjustment for screwdriving work.
Kickback Monitoring: Helps stop the tool when sudden blocking or kickback is detected.
Electronic Torque Shut-Off: Helps provide controlled and repeatable fastening.
Dimmable LED: Improves visibility around the work area.
2 × 5Ah Batteries: Provides extended working capacity and allows one battery to be charging while the other is in use.
AMPShare Compatibility: Works with compatible 18V AMPShare batteries, as well as Bosch Professional 18V batteries from 2008 onward.
L-BOXX Storage: Provides convenient transportation and organized storage for the drill and accessories.
