The Fein ABH 18-26 AS N00 Cordless Rotary Hammer Drill is a professional 18V rotary hammer designed for efficient drilling and chiselling applications in concrete, masonry, steel and wood. Equipped with a powerful brushless motor and 2.6 Joules of impact energy, it delivers rapid drilling progress and strong chiselling performance.
The machine features an SDS-plus tool holder and can drill holes up to 26 mm in concrete. Its compact design, low-vibration operation, integrated LED work light and ergonomic handling make it suitable for demanding construction, installation and renovation applications.
The ABH 18-26 AS is part of the 18V AMPShare battery system and is also compatible with Bosch Professional 18V batteries. Advanced protection features including Kickback Monitoring, Electronic Precision Control (EPC), overload protection and electronic cell protection help provide controlled and safe operation.
Key Features
Professional 18V cordless rotary hammer drill
Powerful brushless motor
2.6 J impact energy for fast drilling and chiselling
SDS-plus tool holder
Up to 26 mm drilling capacity in concrete
Up to 68 mm drilling capacity in masonry
Up to 13 mm drilling capacity in steel
Up to 30 mm drilling capacity in wood
No-load speed of 0–980 RPM
Impact rate of 0–4,350 BPM
Kickback Monitoring with intelligent rapid shutdown
Electronic Precision Control (EPC) for controlled starting
Variable speed control through throttle
Vario-Lock with 36 chisel positions
Integrated LED work light
Compact and ergonomic construction
Compatible with AMPShare 18V batteries
Compatible with Bosch Professional 18V batteries
L-BOXX storage and transport system
Technical Specifications
Specification
Details
Brand
Fein
Model
ABH 18-26 AS N00
Product Number
7 140 03 61 00 0
Part Number
71400361000
Product Type
Cordless Rotary Hammer Drill
Battery Voltage
18V
Battery Interface
18V AMPShare
Battery Compatibility
Li-ion / ProCORE Li-ion
Motor
Brushless
No-Load Speed
0–980 RPM
Impact Rate
0–4,350 BPM
Impact Energy
2.6 J
Tool Holder
SDS-plus
Concrete Drilling Capacity
26 mm
Masonry Drilling Capacity
68 mm
Steel Drilling Capacity
13 mm
Wood Drilling Capacity
30 mm
Weight Without Battery
3.20 kg
Sound Pressure Level
88 dB
Sound Power Level
99 dB
Vibration Value
15.2 / 9.9 m/s²
Battery
Not included
Charger
Not included
Specifications are based on FEIN's current official ABH 18-26 AS product data.
Applications
The Fein ABH 18-26 AS is suitable for:
Drilling holes in concrete
Drilling in masonry and brickwork
Drilling in steel
Drilling in wood
Concrete anchor and fixing installation
Electrical and plumbing installation
Construction and renovation work
Chiselling and light demolition work
Installation of pipes, conduits and fixtures
General professional building-site applications
Safety & Performance Features
Kickback Monitoring
The intelligent Kickback Monitoring system can rapidly shut down the hammer drill if a sudden kickback is detected, helping improve user protection.
Electronic Precision Control
EPC gradually increases the working speed, providing improved control when working on sensitive materials and challenging surfaces.
Vario-Lock
The chisel position can be adjusted and locked in 36 positions, allowing the user to select a suitable working angle.
AMPShare Compatibility
The ABH 18-26 AS works with 18V AMPShare batteries and Bosch Professional 18V batteries, providing flexibility when using an existing compatible battery platform.
Key Benefits
Powerful 2.6 J impact: Efficient drilling and chiselling performance.
26 mm concrete capacity: Suitable for a wide range of professional installation tasks.
Brushless motor: Designed for efficient and durable cordless operation.
Cordless convenience: No mains cable required when used with a compatible AMPShare battery.
Enhanced control: EPC and variable throttle help provide controlled operation.
User protection: Kickback Monitoring provides rapid shutdown in sudden kickback situations.
