Buy GB MIG 400 IJ New Welding Machine Online at Best Price in India

GB MIG 400 IJ NEW Welding Machine – Advanced Industrial MIG/MAG Welding System

The GB MIG 400 IJ NEW Welding Machine is a next-generation 400A CO₂ MIG/MAG inverter welder designed for heavy-duty industrial fabrication, structural steel manufacturing, automotive production, and engineering applications. Built with advanced IGBT inverter technology, it delivers exceptional arc stability, smooth wire feeding, deep weld penetration, and minimal spatter for high-quality welding results.

Operating on a 3 Phase 380V AC power supply, the MIG 400 IJ NEW features a digital control panel, optimized wire feeding system, and continuously adjustable welding parameters. It supports 0.8mm, 1.0mm, and 1.2mm welding wire, making it suitable for welding mild steel, carbon steel, and low-alloy steel in demanding industrial environments.

Features:

• Brand: GB
• Model: MIG 400 IJ NEW
• Product Type: CO₂ MIG/MAG Inverter Welding Machine
• Technology: Advanced IGBT Inverter Technology
• Input Voltage: 3 Phase AC 380V ±15%
• Frequency: 50/60Hz
• Maximum Output Current: 400A
• Output Current Range: 50–400A
• Digital Current & Voltage Display
• Stable Arc with Low Spatter
• Excellent Weld Formation
• Strong Pulse Arc Starting
• Stable Wire Feeding System
• High Deposition Efficiency
• Energy-Saving Inverter Design
• Forced Air Cooling
• Over-Voltage, Over-Current & Thermal Protection
• Suitable for Continuous Industrial Welding

Specifications:

• Input Voltage: 3 Phase AC 380V ±15%
• Frequency: 50/60Hz
• Rated Input Power: 18kVA
• Rated Input Current: 24A
• Output Current: 50–400A
• Output Voltage: 12–40V
• No Load Voltage: 63V
• Duty Cycle: 60%
• CO₂ Gas Flow Rate: 15–20L/min
• Efficiency: 86%
• Protection Class: IP21
• Insulation Class: F
• Wire Diameter: 0.8mm, 1.0mm & 1.2mm
• Dimensions: 550 × 290 × 490mm
