GB ZX7 300 Welding Machine – Professional Portable ARC Inverter Welding Machine
The GB ZX7 300 Welding Machine is a powerful 300A MMA (Manual Metal Arc) inverter welding machine designed for fabrication workshops, construction sites, maintenance work, agricultural equipment repair, and industrial applications. Built with advanced IGBT inverter technology, it delivers stable arc performance, easy arc ignition, reduced spatter, and excellent power efficiency for smooth and reliable welding.
Operating on a 230V single-phase AC power supply, the GB ZX7 300 provides an adjustable welding current from 20A to 300A, making it suitable for welding mild steel, carbon steel, stainless steel, and low-alloy steel. Its compact and lightweight design, combined with VRD safety, Hot Start, and Arc Force functions, makes it ideal for both workshop and field welding.
Features:
- Brand: GB
- Model: ZX7 300
- Product Type: MMA ARC Inverter Welding Machine
- Technology: Advanced IGBT Inverter Technology
- Input Voltage: 230V AC, Single Phase
- Frequency: 50/60Hz
- Output Current Range: 20–300A
- Maximum Output Current: 300A
- Digital Current Display
- VRD (Voltage Reduction Device)
- Hot Start Function
- Arc Force Control
- Easy Arc Ignition
- Stable Arc with Low Spatter
- Compact & Lightweight Design
- Energy-Efficient Performance
- Forced Air Cooling
- Over-Voltage, Over-Current & Thermal Protection
- Suitable for Continuous Workshop & Site Welding
Specifications:
- Input Voltage: 230V AC, Single Phase
- Rated Input Capacity: 8.9kVA
- Rated Input Current: 36A
- Output Current: 20–300A
- No Load Voltage: 56V
- Duty Cycle: 60%
- Efficiency: 85%
- Power Factor: 0.93
- Electrode Diameter: 2.5–4.0mm
- Protection Class: IP21
- Insulation Class: F
- Dimensions: 450 × 160 × 303mm
