Features

Inverter-based digital wave control GMAW and FCAW welding outfit.
Higher efficiency and higher power factor results in greater power saving.
Designed to work even under high ambient temperatures up to 500C.
Light weight and compact MIG/MAG/FCAW welding outfit.
Unique design of three layer and four room dust-free structure
RX1 series is manufactured as per Std. IEC 60974-1:2000/GB 15579.1:2004.
Fresh tip treatment and burn-back time control are adjustable.
Works on 50/60Hz frequency in power supply.
Equipped with synergic mode (unitary function) in which welding voltage is set based on the welding current value automatically. The voltage can be adjusted finely to fit the beast current values.
Digitally controlled waveform enables superior arc characteristics.
Over voltage and under voltage protection
Overheating protection
Single phasing protection
Protective 8 Amps fuse for protection of wire feed motor.

TECHNICAL DATA:

POWRE SOURCE

INPUT SUPPLY Voltage (V) :    415, +15%, -20%
Phase/Freq (No./Hz):    3ph/50-60
Max, input KVA @ 415Vac    -
@ 60% duty cycle (KVA/KW) :     16.2/15.6
@ 100% duty cycle (KVA/KW):     -

OUTPUT   -
Rated Current Range(Amps):     50-400
Rated output range (V):     16.5-35.5
Welding current (400C)
@60% Duty cycle (Amps) :     400
@100% Duty Cycle (Amps):     310

General    -
Power control method:     IGBT inverter controlled
Digital display:     4 digit 7 segment LED Display
Wave from control:     Digitally controlled wave form
Welding sequence
    a. Main welding
    b. Main welding crater (crater repeat is available)
    c. Main welding crater (crater repeat is available)
Ingress protection (Class):     IP 23S
Insulation (Type):     H
Cooling:     Forced air cooling
Power Factor (Degree C):     >0.9
Operating Temperature:     -10 to 50
Dimension (L X B X H):     545 x 380 x570
Weight (KG):     52

Wire feeder
Rated welding current (amps):     400
Applicable wire diameter:     0.8, 1.0, 1.2
Cable length:     1.8m(gas hose 4.8m)
Weight:     10.5
Wire feed speed :    5.3-20.1
Duty cycle:     60

Welding torch :     400
Duty cycle (10 min cycle):     400 Amps, 60% (CO2) 360 Amps, 60% (CO2+Ar)
Duty cycle (continuous):     310 Amps, 100%(CO2) 280 Amps, 100% (CO2+Ar)
Applicable wire diameter(mm) :     08., 1.0, 1.2
Cable length(meter):     3
Weight (incl. cable)(KG):     2.8
