The Ralli Wolf ENOVA 40 Magnetic Drill Machineis designed for accurate and efficient drilling in steel plates, structural steel sections and metal fabrication applications. Its 1200W motor and 400 RPM no-load speed support core drilling up to 40mm diameter and 50mm depth.
Featuring a high-adhesion magnetic base, an integrated coolant system and a compact industrial design, the ENOVA 40 is suitable for fabrication workshops, equipment maintenance and on-site metalworking. Its 97mm stroke provides movement for drilling operations, while the 19.05mm self-adaptor accommodates compatible tooling.
Key Features
1200W full-load power input
Maximum core drilling capacity of 40mm diameter × 50mm depth
400 RPM no-load speed
Strong magnetic adhesion of 10,787N
Integrated coolant system for improved cutting performance
97mm spindle stroke
19.05mm self-adaptor size
Compact magnetic base measuring 165 × 80 × 45mm
Designed for industrial metalworking and steel fabrication
Applications
Structural steel drilling
Steel plate and metal section drilling
Industrial fabrication workshops
Machinery installation and maintenance
Construction and infrastructure projects
Metalworking and engineering applications
On-site drilling on suitable ferrous metal surfaces
Technical Specifications
Specification
Details
Brand
Ralli Wolf
Model
ENOVA 40
Machine Type
Magnetic Core Drilling Machine
Rated Voltage
235V
Power Input (Full Load)
1200W
Full-Load Current
6.0A
No-Load Speed
400 RPM
Maximum Core Drilling Capacity
40mm diameter × 50mm depth
Operation
Single-speed
Magnetic Adhesion
10,787N / 1100kgf
Adaptor Size
Self-adaptor, 19.05mm
Stroke
97mm
Magnet Dimensions
165 × 80 × 45mm
Net Weight (without accessories)
13.2kg
Package Details
Standard accessories listed for the ENOVA 40 include:
