RILON AC/DC 500P IGBT AC/DC INVERTER BASED WELDING MACHINE

Product Code:

Availability:In stock

Rs. 265,146.00 Rs. 189,390.00 189,390.00

Qty

Ask about this product

RILON AC/DC 500P IGBT AC/DC INVERTER BASED WELDING MACHINE

Features:

  • Multifunctional pulse tig, ac/dc and mma function
  • with 2T/4T and repeat function
  • Up slope and down slope function adjustable
  • post flow 0-10s adjustable
  • Pulse frequency and pulse width adjustable
  • Start current, base current, peak current and crater current adjustable
  • With remote control function
  • Wide raange for input voltage: 380V ± 15%
  • Adopt advanced module IGBT technology.

Specification:

Parameters Specification
Input Voltage AC380V+-15%1P
Input Frequency 50/60
Related Input Current TIG:29A MMA:22A
Input Power TIG:18.9KVA MMA:14.5KVA
Open circuit Voltage 70V
Current Range 30-500
Duty Cycle 60%
Arc-Initiating (TIG) H-F
Efficiency 85%
Power Factor 0.93
Protection Class IP21
weight 85 KG
Dimensions 760X380X820 mm
